Description
Amp Type: Tube
Rectifier Type: Silicon Diodes
Preamp Tubes: 5x Mesa 12AX7
Power Amp Tubes: 4x Mesa 6L6 (or EL34)
Maintenance Free Fixed Bias
Wattages : 25, 45, or 90 Watts – Channel Assignable
Power Amp Details Class Wattage
MESA/Boogie’s exclusive Simul-Class™ Power Amp featuring Multi-Watt™ (Patent 7,602,927) with Incremental Wattage Reduction (Patent 9,917,560) which provide three power and two operating-class options that are channel assignable via 25/45/90 Watt Power Switches: Choose 2 power tubes operating in Class A Triode, producing 25 Watts – 2 tubes running in Class A Pentode, producing 45 Watts, or 4 tubes running in MESA/Boogie’s legendary Simul-Class Power that blends the best of Class A and Class A/B simultaneously to produce 90 Watts of pure tonal magic.
Number Of Style Modes: Nine
Number Of Style Modes Per Channel: Three
Channel Controls
Each Channel features: Independent 3-Position Style Mode Switch, Graphic EQ Assignment Switch (On, Off or Footswitchable), Patented Watt Multi-Watt™ 90/45/25 Power Amp Switch, Gain, Treble, Mid, Bass, Presence, & Master Controls, Reverb (Footswitchable), and an 8-Position CabClone IR Select Control (back-panel)
Graphic Eq And/or Contour
Selectable 5-Band Graphic EQ (Footswitchable, Channel Assignable or Off)
Reverb Effects Bypass Options
Footswitchable, All-Tube, Long Spring Reverb with Independent Channel Controls
Effects Loop Bypass Options
Tube-Buffered FX Loop (Footswitchable)
External Switching Jack Options And/or Midi
MIDI Switchable/Programmable via Control Change and Program Change messages, with 256 Preset Location (MIDI IN, MIDI Thru/Out, MIDI Channel, & Store Switches) – Controls Channels 1, 2, 3, Reverb, FX Loop, & Graphic EQ
Speaker Outputs
Two 8 Ohm and Two 4 Ohm
Cabinet Simulation Direct Live recording Output
Built-in, channel assignable, MESA CabClone™ IR Cab Simulator featuring 8 MESA Cabinet IRs, USB Connection for IR transfers, Internal Amp Load for cabinet-free use, Input Level Control, IR Balanced XLR Direct Output, (Dry) Line Output (Uncompensated, +4db Direct Line Output for external cab sim/IR use, Re-Amping, etc.), Headphone Output, IR Output Level Control & Ground/Lift Switch
Channels & Modes
3 Channels / 9 Modes
Mode Voicings styles
Ch. 1 = Clean, Fat, or Crunch
Ch. 2 = Fat, Crunch, or Mark VII™
Ch. 3 = Mark IIB™, Mark IIC+™, or Mark IV™
Graphic Eq Reverb Fx Solo
Graphic EQ, Reverb, FX Loop, CabClone IR
Foot switchable Functions
Ch. 1, 2, 3, Reverb, FX Loop, & Graphic EQ
Speakers Impedance
1 – 8 Ohm Celestion Custom 90 / Total Load = 8 Ohms
Weight
58 Lbs.
Dimensions
18 1/4″ H x 18 3/4″ W x 11 1/2” D
